Showing all 10 results
Jual Immuno Analyzer – Immunoassay adalah tes yang mengandalkan biokimia untuk mengukur keberadaan dan / atau konsentrasi analit.
Analit dapat berupa protein besar, antibodi yang dihasilkan seseorang sebagai akibat dari infeksi atau molekul kecil.
Hot
AFIAS 1
In stock
SKU:
PGA-AFIAS1
| QC/Calibration | 2 calibrators & 2 controls Internal & external controls available |
|---|---|
| Interface | 5” touch screen Built-in thermal printer RS 232/USB port/Ethernet/SD card slot LIS/HIS compatible |
| Memory | 5,000 patient results 5,000 QC results 500 ID chips 100 User IDs |
| Throughput | Up to 10 tests/hour |
| Analyzer | 320 x 204 x 180 mm 3.9 kgs 100 – 240V AC, 50-60Hz Internal temperature control |
Hot
Hot
Hot
AFIAS 6
In stock
SKU:
PGA-AFIAS6
| QC/Calibration | 2 calibrators & 2 controls Internal & external controls |
|---|---|
| Interface | 7” touch screen Built-in thermal printer RS 232/USB port/Ethernet/SD card slot LIS/HIS compatible |
| Memory | 5,000 patient results 5,000 QC results 500 ID chips 100 User IDs |
| Weight | 1.5 kg |
| Analyzer | 420 x 336 x 293 mm 15.1 kgs 100 – 240V AC, 50-60Hz Internal temperature control |
Hot
iCHROMA II
In stock
SKU:
PGA-ICHROMAII
| Specifications | 276 x 220 x 91 mm 1.3 kgs 100 – 240V AC, 50-60Hz Internal & external battery |
|---|---|
| QC / Calibration | System check cartridge Internal & external controls |
| Throughput | Up to 30 tests/hour |
| Interface | 7” touch screen Built-in thermal printer USB port / Ethernet / SD card slot WiFi and bluetooth dongle (optional) LIS/HIS compatible |
| Memory | 1,000 patient results 1,000 QC results 100 User IDs |
Hot
Hot
LIAISON-XL
In stock
SKU:
PGA-LIAISONXL
| Overview | System description : Random access or batch immunoassay system Throughput : Up to 180 tests per hour Time to first result : 17 minutes – assay dependent Assays on board : 25 |
|---|---|
| Samples and Sample Handling | Sample racks : 6-mm to 15-mm internal diameter. Up to 100-mm height Sample capacity : 120 samples, 12-position sample racks in a 10-lane sample area Walk-away time : Approximately 6 hours Stat handling : STAT may be assigned to any position in the sample area Sample type : Serum / plasma / urine / CSF Sample integrity control : • Pneumatic-based level sensor • Aspirated/dispensed volume detection and flagging • Clot detection and flagging Sample carryover : Absent due to the use of LIAISON® XL Disposable Tips |
| Barcodes | Sample tubes (all reading types may be active simultaneously) : EAN / Code 128 / Code 39 / Cod-a-bar / Interleaved 2 of 5 Control sera : 2D barcodes recognized by hand-held scanner |
| Reagents and Reagent Handling | Reagent cooling : 13°C ± 2°C / 52°F ± 59°F Reagent integrity control : • Radio Frequency identification (RFID) • Automatic inventory tracking and updating to integral RFID tag • Tracking of calibration validity • Tracking of on-board stability Reagent capacity : 25-position cooled storage for reagent integrals + 4 position cooled storage for reagent ancillaries |
| Consumable Capacity | Cuvettes : On board capacity: up to 1000 Disposable Tips : On board capacity: 576 DI Water : 10-L container + 2-L reservoir Wash Buffer : 10-L container + 2-L reservoir System cleaning solution : 2-L container |
| Waste Capacity | Solid waste : Up to 2500 Disposable tips and cuvettes Liquid waste : A second container allows an instrument autonomy of 15 min 2 x 10-L containers |
| Continuos Operation | Loading/unloading of items during system operation Includes: Sample racks / Reagent integrals / Ancillaries / Cuvettes / Disposable tips / Control racks / Wash liquid / System liquid / Liquid waste / Solid waste / Starter reagents |
| User Interface | Operating system Monitor GUI : Microsoft® Windows® 17” diagonal LCD touch sensitive screen • Quick access to all pages • Critical events and actions recorded • Software-guided and logged maintenance |
| Results Management | Viewing and editing : • Results available at all times • Sort, search, filter (display customization available) • Possibility of evaluation, validation and release of results prior to printing or LIS reporting Retest : Retest always available, even automated based on predefined rules Back-up : Results can be stored manually or automatically Privacy/safety : Compliant with privacy / safety regulations |
| Quality Control | Package : Long-term monitoring including L-J graphs covering Westgard and RiliBÄK rules Access : Accessible at all times Rule definitions : Available to users |
| Environmental Features | Operating temperature : 15-32°C / 59°F ± 90°F Operating humidity : 10%-85% RH non condensing Electrical : 90-240v, 50-60 Hz Dimensions (excludes monitor and accessories) : Height: 59 in or 150 cm Width: 59 in or 150 cm Depth: 36 in or 90 cm Weight : LIAISON® XL 661 lbs or 300 kg (includes Monitor and Accessories) Noise : 63.9 dBA at operator normal position |
Hot
Maglumi 800
In stock
SKU:
PGA-MAGLUMI800
| Reagent Feature | – Flash chemiluminescence label-ABEI, with high sensitivity and long stability. – Nano magnetic microbeads separation, fast and efficient |
|---|---|
| Main Features | – Througput up to 180 test/hour – 24 hours ready to use – Time to first result 17 minutes |
| Modes of operation | – Random, Batch and STAT |
| Sample Loading | – Up to 40 sample tubes – Continuous loading, STAT available – Barcode reader recognition of analyzer automatic numbered – LIS connection, automatic read sample information – Refrigated sample area with independent power supply |
| Power | AC 80V ~ 50-60Hz, <80W |
| Reagent Loading | – 9 Reagent on board – Continuous loading – RFID reading all info of reagent – Refrigerated reagent area |
| Reagent Integral | – Ready-to-use, no pretreatment required – Including calibrators – RFID tag storing all info of reagent – RFID tag with build-in master curve – 1-point calibration to adjust master curve – Calibration stability max 4 weeks |
| Other Features | – Clot detection – Liquid level detection – Automatic and optional ratio for high sample dilutions – Contstant 36,8C + 0,5C incubation |
| Operation System | – Windows 7 – DELL compatible (Dual-core CPU) – Color Touch screen |
| Interconnection | – Bidirectional LIS connection by TCP/IP and COM |
| Dimension Weight | – Input AC 110/230 Vac, 50/60 Hz, max 630W – Dimension and Weight 102*72*56 cm 73 kg |
Hot
Optical Q
In stock
SKU:
PGA-OPTICALQ
| Test Method | Quantitative Fluorescence Immunoassay |
|---|---|
| CV | <10% |
| Dimensions | 357 mm (L) x 284 mm (W) x 156 mm (H) |
| Weight | 1.5 kg |
| Power Supply | DC 12V/5A, AC/DC Adaptor |
| Data Output | LCD / Internal printer |
| Memory | 99 patient results |
| Interface | RS422 (RJ45) / mini 5pin / USB |
| Display LCD | 5”Mono LCD |
| Working Condition | Temperature: 15-30°C / Humidity: 10-70% |
