Chempro 3.0
Dilengkapi dengan layar sentuh 4,3 inci, Chempro ini memiliki antarmuka pengguna yang intuitif dan mudah digunakan.
Penyimpanan data hingga 3.000 hasil memungkinkan pengguna untuk melacak riwayat pengujian dengan mudah, dan alat ini juga dilengkapi dengan baterai lithium bawaan yang mendukung penggunaan portabel tanpa harus terhubung ke sumber listrik.
Baca lebih lanjut spesifikasinya dibawah ini :
13
People watching this product now!
Description
Chempro 3.0 adalah analyzer biokimia kering portabel yang dirancang untuk memberikan hasil tes biokimia yang cepat dan akurat dengan teknologi deteksi fotometrik.
Alat kimia klinik ini sangat ideal untuk digunakan di laboratorium klinis, pusat kesehatan, dan situasi point-of-care testing, di mana waktu respons cepat sangat penting. Dengan desain yang ringkas dan bobot ringan, Chempro 3.0 mudah untuk dipindahkan dan digunakan di berbagai lokasi.
Keunggulan Chempro 3.0
Chempro 3.0 mampu mendeteksi berbagai jenis sampel, termasuk serum, darah utuh, dan plasma, dengan volume sampel hanya 45μL, menjadikannya hemat dalam penggunaan sampel. Waktu deteksi yang cepat, kurang dari 3 menit, memungkinkan pengguna untuk mendapatkan hasil pengujian dengan segera, meningkatkan efisiensi diagnostik dan penanganan pasien. Alat ini memiliki koefisien variasi (CV) di bawah 10%, sehingga memastikan akurasi hasil yang tinggi.
Dilengkapi dengan layar sentuh 4,3 inci, Chempro ini memiliki antarmuka pengguna yang intuitif dan mudah digunakan. Penyimpanan data hingga 3.000 hasil memungkinkan pengguna untuk melacak riwayat pengujian dengan mudah, dan alat ini juga dilengkapi dengan baterai lithium bawaan yang mendukung penggunaan portabel tanpa harus terhubung ke sumber listrik.
Chempro 3.0 dapat beroperasi dalam suhu antara 15°C hingga 35°C dengan kelembaban relatif di bawah 85%, dan disimpan pada suhu 20°C hingga 60°C dengan kelembaban relatif antara 10% hingga 90%. Dengan dimensi yang ringkas (157.5145.764.6 mm) dan berat hanya 622g, alat ini dirancang untuk kepraktisan dan kemudahan transportasi, serta mendukung pengoperasian dengan adaptor listrik atau baterai internal.
Secara keseluruhan, Chempro 3.0 menawarkan solusi diagnostik biokimia yang efisien, cepat, dan akurat, ideal untuk berbagai aplikasi medis di lapangan atau laboratorium dengan kebutuhan mobilitas tinggi.
Additional information
| Detection Method | Photometric detection |
|---|---|
| Detection time | <3mins |
| CV | <10% |
| Sample Type | Serum, whole blood, plasma |
| Sample volume | 45uL |
| Power supply | Adapter input AC100~240V,50/60Hz, 30VA: Output 5V,2A |
| Built-in Lithium battery | DC 3.7 +- 0.3V |
| Measurement | 157.5*145.7*64.6mm |
| Weight | 622g |
| Data storage | 3000 results |
| Display | 4.3′ touch screen |
| Storage environment | Temp 20C ~ 60C; Rh: 10% ~ 90% |
| Operation environment | Temp 15C ~ 35C; Rh:<85% |
Reviews (0)
Shipping & Delivery
Related products
BS 3000M SINNOWA
In stock
SKU:
PGA-BS3000M
| Methods | End point, Two points, Multi standard, Kinetic, Bichromatic and Serum blank, ect. |
|---|---|
| Test Program | 200 items, which may be modified and deleted |
| Capacity of Flow Cell | 32ul |
| Temperature Control | 25 ℃, 30 ℃, 37±0.1, room temperature. |
| Optical System: | Interferential filters, 340 / 405 / 492 / 510 / 546 / 578 / 620nm and two more filters available. |
| Light Source | 6V 10W halogen lamp. |
| Photometric Range | 0-2.5A |
| Display | LCD screen |
| Printer: | Built-in thermal printer |
| Serial Output | RS-232 standard |
| Dimension | 39cm×37cm×18cm |
Chemray 240
In stock
SKU:
PGA-CHEMRAY240
| Throughput | Lebih dari 160 test / jam. |
|---|---|
| Konten Pengujian | Clinical Chemistry, Immunoturbidimetric. |
| Mode Analisa | End-point, Two-point, Kinetic. |
| Programming | Open system with user defined programs. |
| Otomatis | Akses Acak. |
| Posisi Sampel | 40 posisi untuk sampel. |
| Ukuran Sampel | 3 ~ 100 uL, 0,5 uL adjustable. |
| Posisi Reagent | 40 Posisi untuk Reagent. Refrigerated Temperatre : 16C |
| Ukuran Reagent | R1 : 180 ~ 450 uL, 1 uL adjustable. R2 : 30 ~ 450 uL, 1 uL adjustable. |
| Posisi Reaksi | 81 cuvettes, 9 cuvettes/strip. |
| Cuvette | 8 Step Washer System. |
| Ukuran Reaksi | 180 ~ 500ul. |
| Temperatur Reaksi | 37C, Fluctuation 0.2C. |
Glory 127
In stock
SKU:
PGA-GLORY127
| Reading Cuvette | Both flow through cell and direct reading cuvette |
|---|---|
| Photometric System | Light Source 6V/10W halogen lamp |
| Wavelength | 340/405/492/510/546/578/620nm, 2 more filter on request |
| Wavelength Accuracy | 2nm |
| Thermostatic Control | Temperatur 25C, 30C, 37C, Precision 2nm |
| Measuring System | Method : End Point, Fixed Time, Multistandart, Differential, Bichromatic and Immunoturbidimetric. |
| Measuring Range | 0-3.000 O.D |
| Photometric Linearity | 2% (0-3.000 O.D) |
| Photometeric Accuracy | 1% (0-3.000 O.D) |
| Storage | Over 200 programs, 1000 test result |
| Incubator | 20 incubating positions |
| Display | Black-illuminated LCD |
| Printer | Built in thermal printer |
| Interface | RS-232 Serial port for additional PC, USB port on request |
| Power Supply | AC110V / 60Hz or 220V / 50Hz |
| Dimensions | 340mm, 380mm, 180mm |
| Weight | 8.0 Kg |
Mindray BC-6800
In stock
SKU:
PGA-MINDRAYBC6800
| Parameter | 36 reportable parameters (whole blood): WBC, Lym%, Mon%, Neu%, Bas%, Eos%, IMG%, Lym#, Mon#, Neu#, Eos#, Bas#, IMG#; RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, RET%, RET#, IRF, LFR, MFR, HFR, NRBC#, NRBC%; PLT, MPV, PDW, PCT, P-LCR, P-LCC, IPF 18 research parameters (whole blood): HFC#, HFC%, WBC-R, WBC-D, WBC-B, WBC-N, RBC-O, PLT-O, PLT-I, PDW-SD, InR#, InR‰, Micro%, Micro#, Macro%, Macro#, MRV, RHE 7 reportable parameters (body fluid): WBC-BF, TC-BF#, MN#, MN%, PMN#, PMN%, RBC-BF 7 research parameters (body fluid): Eos-BF#, Eos-BF%, Neu-BF#, Neu-BF%, HF-BF#, HF-BF%, RBC-BF 2 histograms for RBC and PLT 3 scattergrams (3D) for DIFF, NRBC and RET 6 scattergrams (2D) for DIFF, BASO, NRBC, RET, RET-EXT, PLT-O |
|---|---|
| Prinsip | SF Cube cell analysis technology for WBC, 5-Part diff, NRBC, RET and PLT-O Focusing Flow-DC method for RBC and PLT Cyanide free hemoglobin measurement |
| Kinerja | Parameter Linearity Range Precision Carryover WBC 0-500×10⁹/L ≤2.5% (≥4×10⁹/L) ≤1.0％ RBC 0-8×10¹²/L ≤1.5% (≥3.5×10¹²/L) ≤1.0％ HGB 0-250g/L ≤1.0% (110-180g/L) ≤1.0％ HCT 0-75% ≤1.5% (30%-50%) ≤1.0％ PLT 0-5000×10⁹/L ≤4.0% (≥100×10⁹/L) ≤1.0％ RET# 0-0.8×10¹²/L ≤15% (RBC≥3×10¹²/L; / 1%≤RET%≤4%) |
| Sample Volume | Predilute mode (capillary blood), Open vial 40μL Manual mode (whole blood), Open vial 150μL Autoloader mode (whole blood), Closed vial 200μL Manual mode (body fluid), Open vial 150μL |
| Throughput | Up to 125 samples per hour (CBC+DIFF) Up to 90 samples per hour (CBC+DIFF+RET) Up to 40 samples per hour (body fluid) |
| Loading capacity | Up to 100 sample tubes |
| Mode | CBC, CBC+DIFF, CBC+RET, CBC+NRBC, CBC+DIFF+RET, CBC+DIFF+NRBC, CBC+DIFF+RET+NRBC, RET |
| Data storage capacity | Up to 100,000 patient results including all numeric and graphical information |
| Printout | Various printout formats and user-defined formats available |
| Operating environment | Temperature: 15ºC~32ºC Humidity: 30%~85% |
Rayto 7300
In stock
SKU:
PGA-RAYTO7300
| Aperture Diameter | WBC 80um; RBC 50um |
|---|---|
| Throughput | 60 samples per hour |
| Sample Volume | Prediluted: 20uL, Whole Blood: 9.8μuL |
| Display | 8.4′ Color LCD, Resolution: 640X480 |
| Alarms | Error messages |
| Carryover | WBC/RBC/HGB<0.5%, PLT<1.0% |
| Input/Output | RS-232, USB, LAN, keyboard and mouse interface |
| Printout | Thermal printer, 55mm width paper, various printout formats, external printer optional |
| Operating Environment | Temperature: 15~35; Humidity: 10%~90% |
| Power Requirement | AC 110-220V, 50/60Hz |
Rayto RT-2600C Elisa Washer
In stock
SKU:
PGA-RAYTO2600C
| Size Plate mode | 96- or 48-well plate or strip |
|---|---|
| Dispense Precision | CV<2.0% |
| Residual Volume | <1 µL |
| Washing Volume | 50~3000µL for 8-way manifold 50~2000µLfor 12-way manifold |
| Washing Cycle | Maximum 99 cycles |
| Strip Washing | 1 to 12 channels adjustable |
| Soaking Time | 0~24 hour |
| Standard Wavelength: | Display 5” LCD |
| Bottle Capacity | 2 liters each |
| Memory | 50 washing protocols |
| Interface | RS-232 |
| Power Supply | AC 220V±10%, 50~60Hz, 110V on request |
| Net weight | 8Kg |
| Dimensions | L×W×H(mm) 390×340×180 |
Selectra Pro XL
In stock
SKU:
PGA-SELECTRAPRO-XL
| Throughput | Up to 450 photometric and electrolyte tests/hour. |
|---|---|
| Reagent System | 64 refrigerated reagent positions for 10 mL, 25 mL and 50 mL reagent bottles Cooled to 10°C +/- 4°C at normal laboratory conditions All reagent positions can be assigned as R1, R2 and R3. |
| Sample System | 80 barcode readable positions All positions fit 13×75 or 16x 100mm primary and secondary tubes and pediatric cups All positions can be used for calibrators, controls, normal, pediatric and STAT samples |
| Pipetting System | 1000 µL reagent syringe: R1 volume 110-400 µL R2 volume 0-180 µL R3 volume 0-180 µL Programmable in 1 µL steps 100 µL sample syringe: Sample volume 1-30 µL Programmable in 0.1 µL steps Pre programmed ratio selectable from ratios 1:2 up to 1:100 with 3 diluents Pre-heated probe with level detection, collision protection and integrated mixer. |
| Cuvette Rotor | Cost effective, semi-disposable cuvette rotor with 48 cuvettes Up to 10.000 tests per rotor Typical reagent consumption 220 µL per test Measurement temperature 37°C, controlled by Peltier elements. |
| Light Source | Quartz-iodine lamp 12V-20W |
| Wavelength Range | Optical unit with 8 position filter wheel 340, 405, 505, 546, 578, 620, 660, 700 nm standard wavelengths Other wavelengths available on request. |
| Photometric Range | -0.1 to 3.0 Absorbance Resolution 0.001 Abs. |
| Analytical Modes (Single, Dual and Triple reagent system) | Kinetic measurement with linearity check Mono- and bichromatic end point measurement with or without bichromatic reagent blank and/or sample blank correction Two point measurement; with or without slope blank Graphic plot of all measuring points Predilution and automatic reflex dilution as needed Range of calibration models Non-linear calibration curves Prozone check for immunology tests Cut-off declaration Calculated tests. |
| Quality Control | Up to 15 controls can be defined, 3 per test Westgard or Basic QC rules Levey-Jennings plots Quality control statistics. |
| Standards and Regulations | CE -IVD CB UL. |
| Dimensions | 117 x 115 x 80 cm (W x H x D) 46.1 x 45.3 x 31.5 in(W x H x D) |
| Weight | 190 kg (419 lbs). |
| Interface | Host-Query interface available Host: RS 232 or Ethernet (TCP/IP) through LIS-2A protocol. |
| Environmental Conditions | Temperature: 15 – 32 °C (59 – 90 °F) Humidity: 15 – 88% RH Altitude: up to 2000 m Plumbing: No dedicated water or drain required Electrical: Voltage: 100 – 240 Vac Frequency: 50 – 60 Hz Power (max): 380 VA . |
| Integrated PC | Touch screen navigation Operating system: Windows™ XP |
| Barcode Reader | Hand held CCD barcode reader used for reagent identification |
| Eco Kit | Enables separate collection of concentrated measurement mixture and dilute (wash) waste |
| Dry ISE Module | Patented Solid State Electrode Technology Indirect measurement Dilution 1:14 Measures Sodium, Potassium, Chloride and CO2. |
| Positive Sample Identification | Positive Sample Identification (PSID) reads all popular barcodes. |
| Printer | Printer supported by MS Windows™. |
| ProActive Maintenance Kit | Complete parts kit for annual preventive maintenance. |
