BIOC Intherma 168
Photometer Intherma 168 adalah penganalisis kimia cemerlang dengan sistem operasi windows, pemrosesan cepat dan perangkat lunak cerdas.
Tersedia dengan harga terbaik hanya di Pusatgrosiralkes.com. Lihat lebih lengkap Spesifikasinya dibawah ini :
15
People watching this product now!
Description
Jual Photometer Intherma 168, penganalisis kimia cemerlang dengan sistem operasi windows, pemrosesan cepat dan perangkat lunak cerdas, memberi pengguna pengalaman operasi yang benar-benar baru.
Photometer Intherma 168 Dilengkapi Fitur Lengkap dan Canggih
Antarmuka yang ramah
- Layar sentuh LCD yang bisa disesuaikan
- Hasil tes ditampilkan secara bersamaan di layar
- Rendah terbawa dengan pembersihan udara antar sampel
- Photometer Intherma 168 Tahan lama untuk bekerja di bawah suhu tinggi hingga 40C
Sistem Pengukuran
- Titik akhir, Kinetika, Dua titik dan Absorbansi
- Metode pengukuran nephelometery imun
- Multi-standar (Linear, Non-Linear)
- Memori untuk reagen kosong dan sampel kosong
Cuvette / Aliran Sel
- 32 sel kuarsa aliran
- Built-in localizer posisi bawah
- Dua dudukan untuk kuvet / sel aliran
- Kontrol suhu peltier
Sistem Optik Photometer Intherma 168
- Lampu halogen-tungsten
- Roda-filter otomatis dengan 8 posisi
- 7 filter interferensi dan 1 filter opsional
Perangkat Lunak Yang Kuat
- Buka reagen
- Alarm self-check dan malfunction
- Lampu perlindungan otomatis
- Uji parameter penentuan pengguna tersedia
- Kurva absorbansi real-time dan tampilan temperatur
Pusatgrosiralkes.com Jual Photometer Intherma 168 ini dengan Harga Termurah dan Pelayanan Terbaik, lihat juga produk sejenis lainnya.
[block id=”footer-product”]
Additional information
| Optic | 340, 405, 505, 546, 578, 620, 670nm. One more optional filter. |
|---|---|
| Light Source | Hologen 6V / 10W. |
| Resolution | 0.001Abs. |
| Photometric Range | 0.000-3 . 000Abs. |
| Stability Of Absorbency | Change<0.005 Abs per hour. |
| Repeatability | CV<0,5 %. |
| Carry over | < 1% |
| Linearity | R>0.999. |
| Flow Cell | 32 ul with peltier temperature control (25′C, 30′C, 37′C). |
| Memory | 200 Tets programs and over 100.000 test result. |
| Display | 7″ TFT LCD. |
| Printer | Builth-in thermal printer. |
| Data Communication | RS-232, SD card and USB. |
| CPU | High speed embedded processor. |
| Power Supply | AC 100-240V, 50/60Hz. |
| Weight | 7 Kg. |
| Dimension (mm) | 420(L) x 310(W) x 152(H). |
